Structure:
All elements of structure are designed for Earthquake Resistant compliance to SEISMIC ZONE-II
Sub structure-RCC framed structure
Super structure - Aluminum Shuttering with Shear core wall
Masonry walls:
160mm Thick shear core walls
Plastering/Rendering:
Internal walls-Gypsum plaster quired), finished with OBD/Emulsion
External walls-Fair faced concrete finish with exterior Emulsion paint
Door:
Main Door Engineered Solid core shutter 40 mm thick veneered on both sides with SS futures Other Doors Engineered
hollow core shutter 32-38 mm thick laminated on both sides with SS Fixtures
Toilet Doors Engineered hollow core shutter 32 mm thick with laminate on both sides with SS Fixture
Plastic laminate, on the internal side. Brushed SS hardware for all doors
Windows:
UPVC Sliding windows with clear glass with provision for mosquito mesh
Flooring:
Living/Dining/kitchen-600mm x 600mm High quality vitrified tiles flooring
Master Bed Room laminated Wooden Flooring
Bed rooms-600mmx600mm high quality vitrified tiles
Balcony/Utilities-600mm x 600mm high quality textured vitrified tile
Common areas Combination of Granite flooring & high-quality Vitrified tiles
Kitchen:
19mm Black granite counter top with one large SS sink with drain board
Ceramic tiles dado for 2 feet height above counter,
Provision for water purifier connection
Toilet:
Premium Branded CP fittings & fixtures
Premium branded Wash basin & Water closet
Premium branded glazed/Ceramic tiles for flooring & up to the false ceiling height
CPVC pipes for hot & cold-water line Suspended pipes in the toilet above false ceiling
Provision for Geyser above false ceiling in every bath room
Dual piping system for flushing & water supply
Painting:
Plastic Emulsion Oil bound Distemper for internal walls & ceilings
Exterior emulsion for external walls
Enamel painting for Metal & Wood surfaces
Water Supply:
Water treatment & softening plant for the entire water supply system
STP/Water recycling plant treated water used for mushing & landscaping
Rain water harvesting techniques to be used to supplement & recharge bore wells
Gravity water system
Electrical:
15 Mark Copper wires
Premium Mostar switches
Sufficient points in all rooms
Provision for Electrical point for split AC in Master Bed Rooms
SKW & 3KW BESCOM power for each 3 Bedroom & 2 Bedroom units respectively
Provision for TV points in Master bedrooms living room
ELCB for each unit
CCTV system for Security surveillance
Captive power DG
100% back up for all common areas and facilities &3KW for 4 Bedroom units 15W for 3 Bedroom units 10KW for 2-bedroom units
Fire Safety Services:
External Fire and Hydrant System Piping Single headed Hydrant stand post Fee Pumps Hydrant, Diesel & Jockey)
Valves and other necessary accessories
