1. STRUCTURE
Structural System : RCC framed structure designed for seismic compliant (Zone 2)
Masonry : 200mm for external walls and 100mm for internal walls
Floor to Floor height (incl. slab) : Will be maintained at 2965mm
2. WALL/CEILING FINISH
Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Premium Emulsion
Ceiling :Finished with 2 coats of putty, 1 coat of primer & 2 coats of Tractor Emulsion
Exterior walls : Finished with 1 coat of primer & 2 coats of Exterior Emulsion with color as per architect's design
Bathroom : Ceramic tile of size 600x600mm till false ceiling height & above will be finished with a coat of primer
Kitchen : Ceramic wall tile of size 600x600mm for a height of 600mm above the counter top finished level
Bathroom ceiling : Grid type false ceiling
3. FLOOR FINISH WITH SKIRTING
Main Flooring : Vitrified tiles of size 1200X600mm
Bathroom : Anti-skid ceramic tiles of size 600x600mm
Balcony : Anti-skid ceramic tiles of size 600x600mm
Private open terrace (if applicable) : Pressed tiles finish
Plunge Pool (Pent House) : Designer tiles (As per selection)
4. KITCHEN & DINING
Kitchen : Platform will be finished with Engineered marble/equivalent slab wide at height of 850mm from the finished floor level
Electrical Point : For chimney, Hob & water purifier (Affordable, Superior & Penthouse units)
:For chimney, Hob, dish washer & water purifier (Pinnacle units)
600mm
CP fitting : American standard/Kohler/equivalent
Sink :Single bowl $$ sink with drain board and pullout faucet
:Single bowl SS sink without drain board and pullout faucet
Dining :Granite Counter top wash basin
5. BALCONY
Handrail : MS handrail as per architect's design
Light fitting : Balcony light fitting will be provided
6. BATHROOMS
CP fittings & Sanitary fixture : American standard/Kohler or Equivalent
One of the bathrooms :Wall mounted WC with cistern, Health faucet, Single lever diverter,
Shower panel with rain shower and hand shower, Granite counter top wash basin, Glass shower partition with door & 2' trench drain in shower area
Other Bathrooms : Wall mounted WC with cistern, Health faucet, Single lever diverter, Rain shower, Granite Counter top washbasin, Glass Shower partition & pest free drain
7. JOINERY
A. DOORS
Main door : Good quality veneer door of size 1200x2300mm and Designer Door with polished finish
: Ironmongeries like Digital door lock of Yale or equivalent, tower bolts, door viewer, magnetic door catcher, etc.,
Bedroom doors :Good quality door frame with double side laminated shutter of
size 1050 X 2100mm (Other units)
:Good quality door frame with double side laminated shutter of
size 900 X 2100mm (Affordable units)
: Ironmongeries like Yale or equivalent lock, magnetic door catcher, tower bolt, etc.,
Bathroom doors : Good quality door frame with double side laminated shutter of
size 900x2100mm (Other units)
:Good quality door frame with double side laminated shutter of size 750x2100mm (Affordable units)
:Ironmongeries like thumb turn lock of Yale or equivalent without key, door bush, etc.,
B. WINDOWS
Windows: Aluminum windows sliding shutter with see through plain glass & MS railing (wherever applicable)
French doors :Aluminum door with sliding shutters with toughened glass
Ventilators : Aluminum ventilators with fixed louvers/openable shutter for ODU access (wherever applicable)
8. ELECTRICAL POINTS
Power Supply : Single Phase for 2BHK
:Three Phase for other BHK'S
Safety device : MCB (Miniature Circuit Breaker) & RCCB (Residual Current Circuit Breaker)
Switches & sockets : Modular box, modular switches & sockets of good quality IS brand
Wires : FRLS (Flame Retardant Low Smoke) copper wire of a good quality IS brand
TV : Point in Living & one of the bedrooms Provision in other bedrooms
Data : Point in Living & one of the bedrooms
USB : Point in Living & one of the bedrooms
Split-air conditioner : Point in Living/Dining and all bedrooms
Foot Lamp : Point in all bedrooms
Exhaust fan : Point in all bedrooms
Geyser : Point in all bedrooms
Back-up : 400W for 2BHK, 500W for 3BHK & 650W for 4BHK
SPECIFICATIONS COMMON TO BUILDING COMPLEX
COMMON FEATURES:
1. Lift : Automatic lift with MS finish
2. Back-up : 100% Power backup for common amenities such as Clubhouse, Lifts, STP, W.TP & common area lighting
3. Owner's Directory : Apartment owner's name directory will be placed in ground floor
4. Lift fascia : Granite cladding for a threshold of 300mm
5. Lift Lobby : Granite flooring at ground level & Tile flooring at other levels
6. Corridor : Tile flooring
7. Staircase floor : Granite flooring at first 4 levels & Tile flooring at other levels
8. Staircase handrail : MS handrail with enamel paint finish.
9. Terrace floor : Pressed tile flooring
10. Terrace doors : Good quality FRP door of size 900x2100mm with paint finish.
: Ironmongeries like thumb turn lock of Godrej/equivalent without key, door
bush, automatic door closer etc...
