Casagrand Keatsway in Nagavara

STRUCTURE

Structural System: RCC Framed Structure designed for seismic compliant (Zone 2)

Masonry: 200mm for external walls & 100mm for internal walls

Floor- Floor height (incl. slab) : Will be maintained at 2950mm

ATT: Anti–termite treatment will be done

WALL FINISH

Internal walls: Finished with 2 coats of putty, 1 coat of primer & 2 coats of Emulsion

Ceiling: Finished with 2 coats of putty, 1 coat of primer & 2 coats of Emulsion

Exterior walls: Exterior faces of the building will be finished with 1 coat of primer & 2 coats of Emulsion paint with color as per architect’s design

Bathroom: Ceramic Tile up to false ceiling height of size 300x600mm & above the false ceiling will be finished with a coat of primer

Kitchen: Ceramic wall tile of size 300x600mm for a height of 600mm above the counter top finished level

Toilet ceiling: Grid-type false ceiling

FLOOR FINISH

Living, Dining, Bedrooms & Kitchen: Vitrified tiles of size 600x600mm

Bathroom: Anti-skid ceramic tiles of size 300x300mm

Balcony & Utility: Anti-skid ceramic tiles of size 300x300mm

Private open terrace (if applicable): Pressed tiles finish

KITCHEN & DINING

Kitchen: Platform will be finished with a granite slab of 600mm wide at a height of 800mm from the finished floor level

Electrical point: For chimney & water purifier

CP fitting: Kohler/ American standard/ Equivalent

Sink: Single bowl SS sink with drain board

BALCONY

Handrail: MS handrail as per architect’s design

BATHROOMS

CP fittings & sanitary fixture: Kohler/ American standard/ Equivalent

One of the Bathrooms: Wall-mounted WC with cistern, Health faucet, Single lever diverter, Overhead shower, hand shower, and granite counter top wash basin

Other Bathrooms: Wall-mounted WC with cistern, Health faucet, Single lever diverter, Overhead shower, and wall-hung wash basin

JOINERY

Main door: Good quality veneer door of size 1050x2100mm with polish finish

Ironmongeries like Digital Door locks of Yale or equivalent, tower bolts, door viewer, safety latch, magnetic door catchers, etc.

Bedroom doors: Good quality skin door of size 900 X 2100mm with paint finish

Ironmongeries like Godrej or equivalent lock, door bush, tower bolt, etc.

Bathroom doors: Good quality FRP door of size 750 X 2100mm with paint finish

Ironmongeries like thumb turn lock of Godrej/equivalent without a key, door bush, etc.

Windows: Aluminum windows with sliding shutters & plain glass

French doors: Aluminum doors with sliding shutters & toughened glass

Ventilators: Aluminum ventilators of fixed / open-able shutter for ODU access (wherever applicable)

ELECTRICAL POINTS

Power Supply : 3 PHASE power supply connection

Safety device: MCB & RCCB (Residual Current Circuit Breaker RCCB)

Switches & sockets: Modular box & modular switches & sockets of good quality IS brand

Wires: Fire Retardant Low Smoke (FRLS) copper wire of good quality IS brand

TV: Point in Living & one of the bedrooms and provision in other bedrooms

Telephone: Point in Living & one of the bedroom

Data: Point in the Living & one of the bedroom

Split-air conditioner: Points in all bedrooms and provision in Living / Dining

Exhaust fan: Points in all bathrooms

Geyser: Points in all bathrooms

Back-up : 750W for 4BHK, 600W for 3BHK, 500W for 2BHK & 400W for 1BHK

COMMON FEATURES

Lift: Elevators of 10 passengers automatic lift will be provided

Back–up 100% Power backup for common amenities such as Clubhouse, Lifts, STP, WTP & selective common area lighting

Name board: The apartment owner name will be provided in ground Level

Lift fascia: Granite / equivalent cladding

Lift Lobby: Granite flooring @ ground level & Tile flooring @ other levels

Staircase floor: Granite flooring

Staircase handrail: MS handrail with enamel paint finish

Terrace floor: Pressed tile flooring

OUTDOOR FEATURES

Water storage: Centralized UG sump with WTP (Min. requirement as per water test report)

Rainwater harvesting : Rainwater harvesting system as per site requirement

STP: Centralized Sewage Treatment plant

Safety: CCTV surveillance cameras will be provided all-round the building at pivota Locations in ground level

Walkway: Walkway spaces well defined as per landscape’s design intent

Security: Security booth will be provided at the entrance/exit

Compound wall: Site perimeter fenced by compound wall with entry gates for a height of 1800mm as per design intent

Landscape: Suitable landscape at appropriate places in the project as per design intent

Driveway: Convex mirror for safe turning in driveway in / out
