1. STRUCTURE
Structural System : RCC Framed Structure designed for seismic compliant (Zone 2)
Masonry : 200mm for external walls & 100mm for internal walls
Floor- Floor height (incl. slab) : Will be maintained at 3000mm
2. WALL /CEILING FINISH
Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Emulsion
Ceiling : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Emulsion
Exterior walls : Finished with 1 coat of primer & 2 coats of Emulsion paint with color as per architect design
Bathroom : Ceramic tile up to false ceiling height of size 300x600mm & above false ceiling will be finished with a coat of primer
Kitchen : Ceramic tile of size 300x600mm for a height of 600mm above the counter top finished level
Bathroom ceiling : Grid type false ceiling
3. FLOOR FINISH WITH SKIRTING
Main flooring : Vitrified tiles of size 1200X600mm
Bathroom : Anti-skid ceramic tiles of size 300x300mm
Balcony : Anti-skid ceramic tiles of size 600X600mm
Private open terrace (if applicable) : Pressed tiles finish
4. KITCHEN & DINING
Kitchen : Platform will be finished with granite slab of 600mm wide at height of 850mm from the finished floor level
Electrical point : For chimney & water purifier
CP fitting : American standard / Kohler / equivalent
Sink : Single bowl SS sink with drain board
Dining : Counter top washbasin wherever applicable
5. BALCONY
Handrail : MS handrail as per architect’s design
6. BATHROOMS
CP fittings & sanitary fixtures : American standard / Kohler /equivalent
One of the bathrooms : Wall hung WC with cistern, Health faucet, Single lever diverter,
Shower column with rain shower and hand shower, Counter top
washbasin, Shower partition and granite flooring for the shower
area.
Other bathrooms : Wall hung WC with cistern, Health faucet, Single lever diverter, Overhead shower and counter top washbasin.
7. JOINERY
a. DOORS
Main door : Good quality frame with double side veneer finish door of size
1050 x 2100mm with designer panel.
: Ironmongeries like digital door lock, tower bolts, door viewer, safety latch, magnetic door catcher etc.,
Bedroom doors : Good quality frame with double side Laminate finish door of size 900 x 2100mm
: Ironmongeries like Godrej or equivalent lock, door stopper, door bush, tower bolt, etc.,
Bathroom doors : Good quality frame with double side Laminate finish door of Size 750 x 2100mm with water proofing on inner side
: Ironmongeries like thumb turn lock of Godrej/ equivalent, door bush, etc.,
b. WINDOWS
Windows : Aluminum windows with sliding shutter and plain glass
French doors : Aluminum doors with sliding shutters and toughened glass
Ventilators : Aluminum ventilators of fixed louvered / open-able shutter for ODU access (wherever applicable)
8. ELECTRICAL POINTS
Power Supply : Single phase power supply connection for 2BHK
Three phase power supply connection for 3BHK & 4BHK
Switches & sockets : Modular box, switches and sockets of good quality IS brand
Wires : Fire Retardant Low Smoke (FRLS) copper wire of a good quality IS brand
TV : Point in Living and one of the bedrooms
Data : Point in Living
Hob Point : Point in the kitchen
Split- air conditioner : Point in Living and one of the bedrooms Provision in other bedrooms
Exhaust fan : Point in all bathrooms
Geyser : Point in one of the bathrooms and provision in other bathrooms
Back-up : 400W for 2BHK, 500W for 3BHK and 650W 4BHK
SPECIFICATIONS COMMON TO BUILDING COMPLEX
COMMON FEATURES:
1. Lift : Elevators of 10 passenger lift will be provided
2. Back – up : 100% Power backup for common amenities such as clubhouse, lifts, WTP,STP & selective common area lighting
3. Name board : Apartment owner name will be provided in ground floor
4. Lift fascia : Granite /equivalent cladding
5. Lift Lobby : Granite flooring @ ground level
6. Corridor : Tile flooring
7. Staircase floor : Granite flooring
8. Staircase handrail : MS handrail with enamel paint finish
9. Terrace floor : Pressed tile flooring
10. Terrace doors : Good quality FRP door of size 900x2100mm with paint finish
:Ironmongeries like thumb turn lock of Godrej/ equivalent without key, door
bush, automatic door closer, etc.,
OUTDOOR FEATURES:
1. Water storage : Centralized UG sump with WTP (Min. requirement as per water test report)
2. Rain water harvest : Rain water harvesting site
3. STP : Centralized Sewage Treatment plant
4. Safety : CCTV surveillance cameras will be provided all around the building at
pivotal locations in ground level
5. Well defined walkway : Walkway spaces well defined as per landscape design intent
6. Security : Security booth will be provided at the entrance
7. Compound wall : Site perimeter fenced by compound wall with entry gates
8. Landscape : Suitable landscape at appropriate places in the project as per design intent
9. Driveway : Convex mirror for safe turning in driveway in / out
10. External Driveway : Interlocking paver block/equivalent flooring with demarcated driveway as per landscape design intent
